MERIDA EONE SIXTY 500 E BIKE
Our price – $6,499.00 (RRP $8199.00)
Please enquire for availability and sizes
OVERVIEW
The new eOne Sixty 500 once again takes podium spot against competing e-enduro bikes. Agile and playful on the downhills due to its perfectly tuned MTB geometry. Then, when it’s time to head back up the brand-new Shimano EP8 motor offers a whopping 85Nm of torque, capable of climbing the steepest, roughest trails with ease. The durable yet lightweight Alloy frame seamlessly integrates the long-range, fast-charging Shimano E8036 630Wh battery (XS:E8035/504Wh) into the lower downtube, then ‘thermo gate’ ventilation ports work to dissipate warm air. A RockShox 35 Gold RL fork offers 160mm of supple, responsive front suspension, paired with an adjustable Rock Shox Deluxe Select+ shock. The ebike specific Shimano Deore 11 speed drivetrain with matching 4 piston hydraulic disc brakes provide high-performance durability, while a 29er front and a 27.5” rear wheel offer up precise steering with maximum traction.
SPECIFICATIONS
| Axles: | MERIDA EXPERT TR including removeable lever, 6/4mm allen key |
|---|---|
| Battery: | Shimano E8036 630Wh (E8035 504Wh XS) / CHARGER: Shimano EC-E6002 2A charging current |
| Bottom bracket: | included |
| Brakes: | Shimano M4100 4 piston |
| Chain: | HG601-11 |
| Chainwheel: | Shimano CRE70B 34 teeth Shimano FCEM600 |
| Colour (text): | SILK GREEN/ANTHRACITE |
| Derailleur rear: | Shimano Deore RDM5100 11 |
| Display: | Shimano SC-E5003 |
| Fender: | C093-02F + C093-02R |
| Fork: | Rock Shox 35 Gold RL Air 160mm suspension travel Tapered 51mm fork offset 29x2.8" max wheelsize |
| Frame: | eONE-SIXTY LITE III material: aluminium 150mm suspension travel 27.5x2.8" max. wheelsize 148x12mm axle standard intube max. 630 Wh |
| Freewheel: | Shimano M5100 11-51 teeth 11 speed |
| Grip: | MERIDA EXPERT EC |
| Handlebar: | MERIDA EXPERT eTR 780mm width 20mm rise |
| Handlebar stem: | MERIDA EXPERT eTRII material: aluminium 35mm diameter 0° stem angle GoPro & Supernova mount 40 mm all sizes |
| Headset: | MERIDA-8152 |
| Hubs: | Shimano MT400-B 110x15mm width front hub 32 spoke holes Centerlock 148x12mm width rear hub 36 spoke holes Centerlock |
| Light(s): | FRONT: LEZYNE E-BIKE POWER STVZO E115, reverse MERIDA Custom Mount / REAR: USB REAR Light CG-214RG |
| Motor/drive unit: | Shimano EP8 85Nm |
| Pedals: | VP VPE-537 |
| Rim: | MERIDA COMP TR 29mm inner width material: aluminium Tubeless ready (tubeless tape and valves not included) |
| Rotor front: | Shimano RT30 203 mm |
| Rotor rear: | Shimano RTEM300 203 mm |
| Saddle: | MERIDA COMP CC V-mount |
| Seat clamp: | MERIDA EXPERT clamp |
| Seat post: | MERIDA COMP TR 30.9mm diameter 0mm setback XS 100mm travel seatpost - S/M 125mm travel seatpost - L/XL 150mm travel seatpost |
| Shock: | Rock Shox Deluxe Select+ |
| Spokes: | Black stainless |
| Tyre front: | Kenda Regolith 29x2.4" wire |
| Tyre rear: | Kenda Regolith 27.5x2.6" wire |
| Weight: | 23.84 kg weighed with 29" wheels and at frame size M, without pedals, incl. lights |
| Wheel size: | 29" / 27.5" |
For further details please see https://www.merida-bikes.com/en/bike/2191/eone-sixty-500
