$2,060.00


Our Price – from $2,060.00



Please enquire for availability of specific sizes / configurations.



THE HARD HITTING
LONG-TRAVEL ENDURO SPECIALIST

When you need to go really big, reach for the 38. Optimized for 160-180mm of travel and packing the same revolutionary feature set as the 36, the 38 redefines what you think a long travel single crown fork is capable of, and sets a new benchmark for confidence, performance, and durability. Welcome to the big time.

FLOATING AXLE

Floating axles might look similar to other axles, but in fact they offer a distinct performance advantage due to their unique ability to match the exact width of the fork’s wheel mounting surface precisely to the front hub flange spacing, thus creating perfect chassis alignment and eliminating unwanted friction between the upper and lower fork legs. Floating axles provide much smoother suspension movement throughout the entire range of the fork’s travel, notably improving sensitivity and overall ride quality.

LOWER LEG BYPASS CHANNELS

As a fork compresses, the air volume within the lower legs decreases, increasing air pressure. The more the fork compresses, the more pressure increases. This effect can have the unintended consequence of preventing full travel from being achieved. Our lower leg channels help alleviate this issue by dramatically increasing air volume within the lower legs and thereby reducing the amount of additional unintended pressure ramping.

BLEEDERS

Our lower leg bleeders allow for atmospheric pressure equalization at the simple press of a button. Pressure build-up in the lower legs dramatically decreases fork performance, preventing full travel from being achieved, and diminishing small bump sensitivity and responsiveness.

LOWER LEG ARCH

Stiffness-to-weight is the ultimate metric for bicycle design. Engineers invest countless hours poring over every ounce of material in an effort to optimize this critical ratio. Our all-new lower leg design pulls out all the stops, shaving every possible gram while making sure not to compromise stiffness or strength requirements of modern enduro and gravity style riding.

ELLIPTICAL STEERER
(ON SELECT MODELS)

The 38’s elliptical steer tube is one of many ways we’ve further optimized stiffness-to-weight, placing more material only where it is needed, and eliminating every ounce of it where it’s not.



OPTIONS & PRICING

SERIES: FACTORY
Wheel Size: 27.5 / 29
Coating Lowers: Shiny Black or Shiny Orange
Travel: 160 / 170 / 180
Rake: 37 / 44 / 51
Axle: 15QR x 110



38 Factory Series FIT GRIP2
$2,595.00 (Currently Available In store)



SERIES: PERFORMANCE ELITE
Wheel Size: 27.5 / 29
Coating Lowers: Matte Black
Travel: 170
Rake: 44
Axle: 15QR x 110 Boost



38 Performance Series Elite FIT GRIP2
$2,409.90



SERIES: PERFORMANCE
Wheel Size: 27.5 / 29
Coating Lowers: Matte Black
Travel: 170
Rake: 44
Axle: 15QR x 110



38 Performance Series FIT GRIP
$2,060.00



For further information on Fox 38 Forks, please see:

https://www.ridefox.com/family.php?m=bike&family=38
